single input voltage 50w

single input voltage 50w FLP series
single input voltage FLP series

　Feature

Screw/Rail amphibious installation;
Natural cooling;
100% Heavy Load test;
Output voltage can be modified : 3V~200VDC;
Convenient installation;

Model	FP50D-12S	FP50D24S
DC voltage	12V	24V
Rated voltage	4.2A	2.1A
Current range	0~4.2A	0~2.1A
Rated power	50W	50W
Ripple and Noise	120mVp-p	150mVp-p
Voltage adjustment range	14~17V	28~34V
Linear adjust rate	±1%	±1%
Load adjust rate	±1%	±1%
Output voltage adjusted ±%	V1:+12V ±10%	V1:+24V ±10%
Efficiency	±75% min	±76% min
Vibration test	2G ,10~500Hz , 3axes
Input range	220VAC
Output	200~380VDC
Keep time	13ms
Input frequency	47~63Hz
Impulse current（25 ℃）	40A/220VAC
Working temperature	-15~+50℃
Work humidity	5~+95%RH
Storage temperature	-20~+85℃
