100WRail power supply

100W FLP series, single voltage input

　Feature

Screw/Rail amphibious installation.
Natural cooling.
100% Heavy Load test.
Output voltage can be modified : 3V~200VDC
Convenient installation.
Voltage digital display

Model	FP100D-24M	FP100D-12M
DC voltage	24V	12V
Rated voltage	4.2A	8.3A
Current range	0~4.2A	0~8.3A
Rated power	100W	100W
Ripple and Noise	240mVp-p	240mVp-p
Voltage adjustment range	28~34V	12×10%
Linear adjust rate	±1%	±1%
Load adjust rate	±1%	±2%
Output voltage adjusted ±%	V1:+24V ±10%	V1:+24V ±10%
Efficiency	±80% min
Vibration test	2G ,10~500Hz , 3axes
Input range	220VAC
Output	depend on model
Keep time	13ms
Input frequency	47~440Hz
Impulse current（25 ℃）	20A/110VAC
Working temperature	-15~+50℃
Work humidity	5~+95%RH
Storage temperature	-20~+85℃
