20W/25W Rail power supply

20W/25W switch Power Supply

　Feature

Screw/Rail amphibious installation.
Natural cooling.
100% Heavy Load test.
Output voltage can be modified : 3V~200VDC.
Convenient installation.

Model：	FP20D-05S	FP25D-12S	FP25D-24S
DC voltage	5V	12V	24V
Rated voltage	4A	2.06A	1A
Current range	0~4A	0~2.06A	0~1A
Rated power	20W	25W	25W
Ripple and Noise	50mVp-p	120mVp-p	150mVp-p
Voltage adjustment range	6~7.5V	14~17V	28~34V
Linear adjust rate	±1%	±1%	±1%
Load adjust rate	±1%	±1%	±1%
Output voltage adjusted ±%	V1:+5V ±10%	V1:+12V ±10%	V1:+24V ±10%
Efficiency	±70% min	±75% min	±76% min
Vibration test	2G ,10~500Hz , 3axes
Input range	180~264VAC
Output	200~380VDC
Keep time	13ms
Input frequency	47~63Hz
Impulse current（25 ℃）	40A/220VAC
Working temperature	-15~+50℃
Work humidity	5~+95%RH
Storage temperature	-20~+85℃

Keep time is in the 110 VAC input and rated load test.

※ Load current: each group output can provide the maximum load , but the total load not more than rating.
※ Line adjust rate: In rated load, from low voltage to high voltage detection.
※ Load adjustment rate: in 110 VAC input ,from 20% to 100% of the rated load test.
※ Ripple and noise: in 110 VAC input and rated load use a 0.1 UF / 630 V metal capacitance and a 47 UF electrolytic parallel to do the test.
※ Efficiency: In the 110 VAC input and rated load test.
