500W Rail power supply

500W Switch Power Supply

　Feature

Screw/Rail amphibious installation.
Natural cooling.
100% Heavy Load test.
Output voltage can be modified：3V~200VDC
Convenient installation.
Voltage digital display

Model：	FP500D-12M	FP500D-12MDA (digital)	FP500D-24M	FP500D-24MDA (digital)	FP500D-68M	FP500D-68MDA (digital)
DC voltage	12V		24V		68V
Rated voltage	41.6A		20.8A		7.3A
Current range	0~41.6A		0~20.8A		0~7.3A
Rated power	300W		300W		300W
Ripple and Noise	120mVp-p		240mVp-p		240mVp-p
Voltage adjustment range	14~17V		28~34V		70~75V
Linear adjust rate	±1%		±1%		±1%
Load adjust rate	±2%		±2%		±2%
Output voltage adjusted ±%	V1:+12V ±10%		V1:+24V ±10%		V1:+68V ±10%
Efficiency	±82% min		±82% min		±82% min
Vibration test	2G ,10~500Hz , 3axes
Input range	90~132/180~264VAC
Output	200~380VDC
Keep time	13ms
Input frequency	47~440Hz
Impulse current（25 ℃）	20A/110VAC 40A/220VAC
Working temperature	-15~+50℃
Work humidity	5~+95%RH
Storage temperature	-20~+85℃

Keep time is in the 110 VAC input and rated load test.

※Load current: each group output can provide the maximum load , but the total load not more than rating.
※Line adjust rate: In rated load, from low voltage to high voltage detection.
※Load adjustment rate: in 110 VAC input ,from 20% to 100% of the rated load test.
※Ripple and noise: in 110 VAC input and rated load use a 0.1 UF / 630 V metal capacitance and a 47 UF electrolytic parallel to do the test.
※Efficiency: In the 110 VAC input and rated load test.
