Pressure measurement of gas and liquid medium;
PNP switch, voltage, current Output optional;
Peak pressure display, scale zoom function, PNP switch point set, support switch action delay;
OLED self luminous liquid crystal display;
Display information of 180 degrees, the main instrument 330 degrees rotation, support unit switch show;
Procurement
| Model |
FGP37S-□-F20 |
FGP37M-□-F20 |
FGP37L-□-F20 |
| Rated pressure range |
0 ~ +1MPa |
0 ~ +10MPa |
0 ~ +40MPa |
| Set pressure range |
0 ~ +1MKPa |
0 ~ +10MPa |
0 ~ +40MPa |
| Pressure resistance |
100MPa |
100MPa |
100MPa |
| Applicable gas |
Air / liquid, non corrosive, non combustible |
| Power supply voltage |
12 to 24 VDC（Even the peak of the wave is 10% below） |
| Consumption current |
24V 25mA MAX, 12v 45mA MAX |
| ComparisonOutput |
Voltage quantity0~5v DC 0~10v / DC Analog can be selected, current quantity0~20mA 4~20mA / Analog can be selected; |
| Repeat accuracy |
±0.5%F. S |
| Reaction time |
<10ms |
| long-term stability |
±0.3%FS / Year |
| Measurement range（Mpa） |
0.1 , 0.35 , 0.7 , 1.6 , 3.5 , 7, 10 , 25 , 40 , 60 |
| Range scaling |
25 % FS - 100% FS |
| Vibration |
≦10g/10Hz...500Hz |
| Collision |
≦50g/11ms |
| Switching delay |
0.00s~99.99s |
| Tolerance environment |
Protection level |
IP65 |
| Ambient temperature |
Preservation: -30~70 (No water dew and non freezing condition） |
| Ambient humidity |
Action and preservation: 0~85%RH (No water gel ） |
| Temperature characteristic |
±1% F.S (25℃) |
| Texture of material |
Case: stainless steel
The display panel: PMMA
The pressure sensing sheet: 17-4/3/16L
Electrical connector: M12Round plug |
| Standard |
Terminal Line2.0m, instruction manual, packing box |
| Matching |
Mounting bracket 1 |
|
